Smart card reader

CSI610

Specification:

• Compliant with the USB2.0 specification.

• Support SD / micro SD / MS / M2 of memory cards reading/writing

• Support major memory cards including the SDXC and latest MSHC.

• Support Smart Card（5V, 3V and 1.8V smart CARDS, ISO 7816 A, B and C classes）

• Plug & play simplicity.

• Auto detect memory card.

• Support USB2.0 Hi speed read transfer rate 480Mpb/s for memory card.

• Supports bus-powered modes

• Support IC CARDS with ISO 7816 T=0 and T=1 protocols and 2 and 3 line memory CARDS or I2C interface synchronization CARDS.

• Supports T=0,T=1 protocol.

• Supports PC Smart Card industry standard-PC/SC 1.0.PC/SC 2.0

• Meets Microsoft WHQL USB Smart Card Reader requirements.

• Supports SIM port for Subscriber ldentity Module Card for phone book editing.

• Red LED lights flash while reading and writing data

• Systerm support:

Memory card: Windows 2000 SP4 / XP SP3 / 2003 / Vista / 7 / Mac OS10.5  or above

Smart Card editor:  2000 SP4 / 2003 / XP SP2 / Vista / win 7 / 8 or above

• Unit Dimensions：（ L x W x H )83.8 x 32 x 14.6 mm

• Unit weight：21g
